Name: 65 Inch Infrared Ir Sensor Black Business Android USB Aluminium screen touch frame overlay touch open frame
Brand: YCLTOUCH
SKU: LT-65-Q9
Price: 1.00 USD
Availability: InStock
Rating: 4.7 (107 reviews)

65 inch infrared touch screen open frame USB interface multi 40 points ir panel for smart overlay kit

infrared touch screen 65 inch multi ir touch frame,ir touch panel overlays with 40 points

Description for LT series infrared touch frame :

65 inch Infrared Touch Frame with 40 points

Model:LT--Q9

20.8mm width 9.5mm thickness frame

Infrared Touch Screen/Frame , Size from 43"-65", 40 point touch with Dust-proof/ Vandal-proof/ Water-proof/ Anit-glare

Product Description
Touch Screen Size	65"
Supporting resolution	432768×32768
Minimum Recognition Point Size	2.5mm
Touch Points	40 touch points
Touch Response Time(Multi touch)	10-15ms
Touch Response Time(One touch)	8ms
Input method	Any opaque touches, such as fingers, brushes, etc.
calibration	4 or 9 points calibration
Number of clicks	Infinite times
Touch pressure	No pressure requirement
Interface type	1.5 m USB cable receptacle, the receptacle 5P
Line length	1.5m
Frame Material	Aluminium alloy
Glass Material	Toughened glass
communication interface	USB 2.0
Power supply mode	USB 5.0V
Characteristic	Easy installation, strong compatibility
Scanning frequency	>110Hz
Working Voltage and Current	4.75~5.25V , ≤200mA
Anti-light Interference	Excellent
Temperature Range	Working temperature:-10℃～50℃,Storage temperature:-20℃～60℃
LED Lifetime	60000hours
ESD	EN 6100-4-2 2008:3 level.4KV contact discharge and 8KV air discharge
Humidity	Up to 90% RH from 0°C to +40°C, non-condensing
Fault-tolerant	Able to work if less than 10% non-consecutive sensors are damaged
Support OS (One touch)	WindowsXP,MacOS.Linux
Support OS(Multi touch)	Windows10,Windows8,Windows7,Andriod
Firmware Upgrade	USB Upgrade: Windows 8,Windows 7

Features & Functions:
1No special touch tools are needed, just opaque objects
2 High definition, Stable touch, accuracy and smooth writing
3 Super-thin,and ultra-narrow frame, aluminium alloy shell
4 Driver-free support for multiple operating systems
5 Long service life, maintenance-free

6 The size can be customized
7 Strong anti-jamming ability, anti-static performance of industrial ESD
8 Well-positioned ,and support multi touch points
9 Response fast, sensor discontinuous damage 10%, can still work

What is a IR Touch Screen ?

YCLTouch IR Touch Frame / Screen is a high-precision IR (Infrared) Multi-touch Screen. with interpolation resolution up to 32768*32768 and can be applied in 10.4''-500'' display.Any nontransparent substance can be detected and located in the screen. IR Multi-touch Screen has many advantages such as high precision, fast response, excellent glare-resistive ability and faulty tolerance, with one time factory calibration.

Our Company

65 Inch Infrared Ir Sensor Black Business Android USB Aluminium screen touch frame overlay touch open frame 2

65 Inch Infrared Ir Sensor Black Business Android USB Aluminium screen touch frame overlay touch open frame 3

Tag:

Place of Origin:	China
Brand Name:	YCLTOUCH
Certification:	RoHS, ISO9001, ce, EMC, LVD
Model Number:	LT-65-Q9

Minimum Order Quantity:	1
Price:	Negotiable
Delivery Time:	3-7Days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	1000/ months

Size:	65 Inch	Response Time:	Response Time: <10ms
Color:	Black	Structure:	Open Frame
Interface Type:	USB	Type:	Infrared
Place Of Origin:	Guangdong, China	Certification:	RoHS, CCC, ISO9001, Ce, FCC, EMC, LVD
